3000T STACKER - DESTACKER

WOOD INDUSTRY - STANDARD

3000T

CONCEPT



  • Stacker or destacker (3.5 cycles / min)
  • For long products up to 13 meters (42 feet)
  • For wide layers up to 2.4 m (8 feet)
  • Complete layer or single timber
  • No adjustment depend on products by using Wave System™ grippers
  • Destacking or stacking layer 3000 kg (6600 Lbs) maximum*
  • Pick or release on multiple positions
  • Not sensitive to dust or moisture





APPLICATION



  • Complete house panels
  • Molder, cross cut saw, rip saw infeed (several lines can be fed with one gantry robot)
  • Joinery machine infeed and outfeed
  • End of line stacking
  • Band saw outfeed
  • Sticking desticking after or before kilns





MORE OPTIONS



  • 2 horizontal axis by using a double axis bridge
  • 180° rotation of the grippers
  • Radio control
  • Telescopic for low roof clearance
  • Switch from single board to complete layer by rotating the gripper
